Help to upgrade Suspension of 2005 Chevrolet 2500

Notices
Like Tree6Likes

Help to upgrade Suspension of 2005 Chevrolet 2500

Old 07-18-2018, 06:35 PM
  #1
Senior MemberCaptains Club MemberPLEDGER
Thread Starter

Join Date: Feb 2001
Location: SE LA
Posts: 5,144
Default Help to upgrade Suspension of 2005 Chevrolet 2500

So earlier this year I bought a 2005 Chevrolet 2500 6.0L Gas 4x4. Use of the truck is only pulling the boat. The ride is terrible. It's not normal 3/4 terrible, it needs work. It also sits pretty low with the boat attached.

Does being lifted have anything to do with the terrible ride? Where do I start? What parts do I need to look for?

Here is a bad picture of it.
Gmack is offline
Old 07-18-2018, 07:10 PM
  #2
Admirals Club Admiral's Club Member

Join Date: Aug 2017
Location: WI
Posts: 237
Default

Billstein shocks. Air down the tires.
billinstuart likes this.
SouthpawHD is offline
Old 07-18-2018, 07:20 PM
  #3
Admirals Club Admiral's Club Member

Join Date: Jan 2013
Posts: 4,586
Default

Firestone air bags in the back. Bilstien 5100 shocks.
avalonandl is offline
Old 07-19-2018, 02:12 AM
  #4
Senior Member

Join Date: Oct 2002
Location: Dryden/Ludington, MI - Steamboat, CO
Posts: 1,292
Default

I'm guessing torsion axles have been cranked to get front end up. That will definitely make it ride like hell. I have 2003 2500. 5100's on it and michilens made it ride alot better than stock, but it still rides like a brick compared to my half ton.
thecubanfishy and GradysDad like this.
Salmonbum is offline
Old 07-19-2018, 03:41 AM
  #5
Admirals Club Admiral's Club Member

Join Date: May 2008
Location: Between Richmond and Williamsburg
Posts: 2,964
Default

Doesn't appear to be lifted much. Check the torsion bar bolts, if they are bottomed out, the "pork chop" is cranked beyond were it should be, a cheap mans "lift"
twobyfour is offline
Old 07-19-2018, 08:36 AM
  #6
Senior MemberCaptains Club Member

Join Date: Jan 2007
Location: Tampa Florida
Posts: 4,939
Default

bilstein shocks all the way around and air tires down a notch as mentioned before. also tires that are a few years old will stiffen and make the ride a little rougher.

other than that, its a 3/4 tun suspension so it will not be great by any means
Rolandt03 is offline
Old 07-19-2018, 09:46 AM
  #7
Admirals Club Admiral's Club Member
THT sponsor

Join Date: Jun 2007
Location: Houston/Sargent, Texas
Posts: 5,329
Default

I have done all the normal mods to 2500 and 3500 chevy's with the same result....a shit ride.

Until I learned about Norcal Nick and Cognito suspension for these trucks I thought I knew it all.

I would seriously consider putting a Cognito kit on the front. The change in the ride is just amazing. People can't believe how well my '16 one ton crew cab long bed rides.
freedbaby is offline
Old 07-19-2018, 10:22 AM
  #8
Senior MemberCaptains Club Member

Join Date: Dec 2007
Location:
Posts: 11,181
Default

Also, if you're running 80 psi in the front tires, it WILL ride like shit. Rattle your teeth out. It's supposed to be 50 psi in front, 80 in rear. Check sticker inside of door.
Back-in-Black is offline
Old 07-19-2018, 01:20 PM
  #9
Senior MemberCaptains Club MemberPLEDGER
Thread Starter

Join Date: Feb 2001
Location: SE LA
Posts: 5,144
Default

Thanks everybody. Will check the tires and torsion bars.

How hard of a job is changing shocks?
Gmack is offline
Old 07-19-2018, 01:25 PM
  #10
Senior Member Admiral's Club Member

HarleyFLHP's Avatar

Join Date: Jan 2012
Location: The great State of NC
Posts: 10,344
Default

Originally Posted by Gmack View Post
Thanks everybody. Will check the tires and torsion bars.

How hard of a job is changing shocks?
A little harder than brushing your teeth.
HarleyFLHP is offline
Old 07-19-2018, 02:04 PM
  #11
Admirals Club Admiral's Club Member

Join Date: Nov 2009
Location: Tarpon Springs, FL
Posts: 7,409
Default

My preference for a leveling kit is BDS with the Fox 2.0 shocks. From memory the 2006 range of those trucks need the airbags just like most 1/2 truck to tow.
mikefloyd is online now
Old 07-19-2018, 04:57 PM
  #12
Senior Member

Join Date: Oct 2002
Location: Dryden/Ludington, MI - Steamboat, CO
Posts: 1,292
Default

Best thing I did to get a better ride out if the 2500 is park a half ton next to it and drive that when 3/4 ain't needed.
Joe likes this.
Salmonbum is offline
Old 07-19-2018, 06:40 PM
  #13
Admirals Club Admiral's Club Member

Join Date: Sep 2012
Location: South Florida
Posts: 557
Default

.
Scubacouple2 is offline
Old 07-20-2018, 06:08 AM
  #14
Senior MemberCaptains Club Member

Join Date: Mar 2004
Location: Fayetteville/Gloucester, NC
Posts: 1,326
Default

The 2500's that I've owned, all stock trucks with no suspension mods, need at least 750 lbs. in the bed to smooth the ride. They're made to carry weight, and they just don't ride well empty.

As suggested, lowering the tire pressures will help also. No need to run 80 psi in the rear unless you're loaded.

But they still don't ride like a 1500.
abfish is offline
Old 07-20-2018, 06:12 AM
  #15
Senior Member

Join Date: Jan 2006
Location: Sunny florida
Posts: 23,006
Default

Originally Posted by Back-in-Black View Post
Also, if you're running 80 psi in the front tires, it WILL ride like shit. Rattle your teeth out. It's supposed to be 50 psi in front, 80 in rear. Check sticker inside of door.
I had my tire pressure monitor reset to 40#'s...huge difference in ride, tire wear is even.
billinstuart is offline
Old 07-20-2018, 06:41 AM
  #16
Admirals Club Admiral's Club Member

Join Date: Jan 2013
Posts: 4,586
Default

Soak the shock nouts in PB blaster for a couple days, should be fairly straightforward.
avalonandl is offline
Old 07-20-2018, 06:57 AM
  #17
Senior MemberCaptains Club Member

Join Date: Dec 2007
Location:
Posts: 11,181
Default

Originally Posted by avalonandl View Post
Soak the shock nouts in PB blaster for a couple days, should be fairly straightforward.
An impact wrench (electric or pneumatic) with a deep well socket is the ONLY way to do those top nuts on the shocks. They come off is seconds. Doing them by hand is a real PITA.
Back-in-Black is offline
Old 07-20-2018, 03:38 PM
  #18
Senior MemberCaptains Club Member

Join Date: Dec 2003
Location: Michigan
Posts: 669
Default

Originally Posted by Salmonbum View Post
Best thing I did to get a better ride out if the 2500 is park a half ton next to it and drive that when 3/4 ain't needed.
I am in the process of doing this.... Actually going Yukon XL with a hefty pickup next to it...

May even go 350/3500...

JasperDog is online now
Old 07-20-2018, 08:37 PM
  #19
Member

Join Date: Sep 2003
Location: Bristol CT
Posts: 33
Default

When I add 500 pounds in the far rear of the bed to aid plowing in the winter, it transforms the ride but I don't feel that a solution for the other 9 months of the year. I have also aired down and bought 5100 bilsteins this week but have yet to install them. I've read good things about Solastic shackles but have not ridden in a vehicle equipped with them.
NickP is offline
Old 07-21-2018, 05:55 AM
  #20
Admirals Club Admiral's Club Member

Join Date: Nov 2009
Location: Tarpon Springs, FL
Posts: 7,409
Default

Originally Posted by billinstuart View Post
I had my tire pressure monitor reset to 40#'s...huge difference in ride, tire wear is even.
That seems a little low for a 2500, I run 50 in the front and 60 in the back of mine. It rides pretty good but hates the brick streets they have in the Tampa/ St Pete area.
mikefloyd is online now
