Default Raymarine Axiom Pro 12 Models


For our resident electrocis guruís:

I have a complete set of Raymarine E125ís (Navionics Platinum+ amd LNC) and with an airmar M260 through hull x-ducer linked to my Merc VV7 and multi engine data sender. I am considering the new Raymarine Axiom Pro and need some advice on what would be ideal or needed to change to twin displays.

What is the Raymaine model E70482-00-NAG versus others? Is Lighthouse 3 a item to add or download? The offerings are a bit confusing...

Does the new axiom pro 12 fit the same hole as the E125/127?

Can I add the 3D external transom mount x-ducer and still have my thruhull?

Do I have to upgrade the radar from my Raymarine Digital (not HD) radome 2010? What about my Raymarine GPS receiver (2010)?
Ctsearay likes this.

Last edited by vyper340; 10-28-2018 at 09:45 AM.
vyper340 is offline
Old 10-28-2018, 05:14 PM
  #2
Admirals Club Admiral's Club Member
THT sponsor

Join Date: Jan 2016
Posts: 7,172
Default

The es125/7 is 13.9" x 8.74"
The Axiom 12 Pro is 14.1" x 9.17"

You may need to enlarge the hole slightly as the overall dims of the Axiom are larger.
Lighthouse is Raymarine in-house charts, some like them some don't.
Yes you can keep your thruhull as well.
InternationalMarineBrian is offline
Old 10-28-2018, 06:37 PM
  #3
Senior Member

Join Date: Jun 2011
Location: Charleston, SC
Posts: 354
Default

The eS series and Axiom Pro are the exact same sizes and use the same templates.
The part number you listed is the Pro S, I recommend getting the Pro RVX if you want 3D and compatibility with dual frequency transducers and Airmar CHIRP transducers.
Get E70372, you can use existing sounder AND add the 3D ducer.
Radar and GPS will be 100% compatible.
vyper340 likes this.
MikeBador is offline
Old 10-29-2018, 07:28 AM
  #4
THT Sponsor
THT sponsor
Thread Starter

Join Date: Jun 2014
Location: 757 VB
Posts: 806
Default

Originally Posted by MikeBador View Post
The eS series and Axiom Pro are the exact same sizes and use the same templates.
The part number you listed is the Pro S, I recommend getting the Pro RVX if you want 3D and compatibility with dual frequency transducers and Airmar CHIRP transducers.
Get E70372, you can use existing sounder AND add the 3D ducer.
Radar and GPS will be 100% compatible.
Is it an option to get one of both (the Pro S and then the RVX) or do both have to be the same? One is a "slave" and I might have a great deal on the Pro S and then would need to purchase the RVX if that is possible.
vyper340 is offline
