Is this tile layout the most efficient?

Notices

Is this tile layout the most efficient?

Old 12-21-2008, 10:13 AM
  #1
Senior MemberCaptains Club MemberPLEDGER
Thread Starter

Join Date: Nov 2004
Location: Oregon Inlet, NC
Posts: 2,661
Default Is this tile layout the most efficient?

Redoing my small bathroom with tile.

Gotta lay it out first because the radiant heat thinset is gonna cover my marks on the floor, therefore I gotta mark the tile corners on the wall before I proceed to lay the electric mat.

What do you guys think, trying to minimize cuts. I got a wet saw.







blueh20pc is offline
Old 12-21-2008, 10:28 AM
  #2
Senior Member

Join Date: Nov 2006
Location: Mobile, Al.
Posts: 1,245
Default Re: Is this tile layout the most efficient?

that will look fine, all of your short cuts will be under the cabinet and behind the toilet out of site.
Domino Effect is offline
Old 12-21-2008, 10:31 AM
  #3
Senior MemberCaptains Club MemberPLEDGER
Thread Starter

Join Date: Nov 2004
Location: Oregon Inlet, NC
Posts: 2,661
Default Re: Is this tile layout the most efficient?

Thanks Lee,

BTW, Merry Xmas and all that whatnot!
blueh20pc is offline
Old 12-21-2008, 10:56 AM
  #4
Senior MemberCaptains Club MemberPLEDGER
Thread Starter

Join Date: Nov 2004
Location: Oregon Inlet, NC
Posts: 2,661
Default Re: Is this tile layout the most efficient?

Buddy of mine just said to remember that I got 3/4" of baseboard trim to install, so I should offset it off the wall.
blueh20pc is offline
Old 12-21-2008, 12:14 PM
  #5
Admirals ClubCaptains Club Member Admiral's Club Member

Join Date: Oct 2007
Posts: 7,095
Default Re: Is this tile layout the most efficient?

blueh20pc - 12/21/2008 1:56 PM Buddy of mine just said to remember that I got 3/4" of baseboard trim to install, so I should offset it off the wall.


I'm not an expert but I think that is the other way around with the trim base board...

I understand that: you want the floor tile to go all the way to the wall and then the baseboard on top of the floor. this way you get the two cut sides together and hidden, with all the "finished" sides exposed...

Did I explain myself correctly??? please could somebody agree or disagree???

edit: sorry I was under the assumption that you were using the same tile to do the baseboard thats why I was talking about keeping cut side together and hidden, but re-read you op and saw something about a 3/4". Either way it's still the same, the trim goes over the cut tile to hide the imperfections of the cuting.
emudryj is offline
Old 12-21-2008, 12:34 PM
  #6
Senior Member

Join Date: Apr 2008
Posts: 545
Default RE: Is this tile layout the most efficient?

I would lay it out like you have it except I would start in the doorway with a whole diagonal piece off of your threshold and sheetrock. Put the cuts at the tub and behind vanity, toilet.
gregGradyfish is offline
Old 12-21-2008, 12:47 PM
  #7
Senior MemberCaptains Club MemberPLEDGER
Thread Starter

Join Date: Nov 2004
Location: Oregon Inlet, NC
Posts: 2,661
Default Re: Is this tile layout the most efficient?

emudryj - 12/21/2008 11:14 AM







I'm not an expert but I think that is the other way around with the trim base board...

I understand that: you want the floor tile to go all the way to the wall and then the baseboard on top of the floor. this way you get the two cut sides together and hidden, with all the "finished" sides exposed...

Did I explain myself correctly??? please could somebody agree or disagree???

edit: sorry I was under the assumption that you were using the same tile to do the baseboard thats why I was talking about keeping cut side together and hidden, but re-read you op and saw something about a 3/4". Either way it's still the same, the trim goes over the cut tile to hide the imperfections of the cuting.
Yes, you're right, I have offspaced it to the left on the first picture by 3/4 inch to allow for my baseboard to cover the tile, giving me a little bit of grout line on each side of the basebaord trim on the "width" of the room so to say.

Also, I'm thinking of cutting 2" strips of 12" tile to threshold the shower and door, making it look a bit more "custom", like I knew what I was doing.

BTW, first time tiling a floor, so.... Let's mix some Thinset!!!!

If it turns out bad I'll post pictures of the hammer I used to smash it up.

I got the tiles for 3$ a box on discount.
blueh20pc is offline
Old 12-21-2008, 01:11 PM
  #8
Senior MemberCaptains Club Member

Join Date: Nov 2001
Location: Charleston, SC, USA!
Posts: 2,181
Default RE: Is this tile layout the most efficient?

gregGradyfish - 12/21/2008 12:34 PM

I would lay it out like you have it except I would start in the doorway with a whole diagonal piece off of your threshold and sheetrock. Put the cuts at the tub and behind vanity, toilet.
I agree, move everything towards the entrance door to get a whole tile there to start. I did not and think it would look much better.

Reelescape1 is online now
Old 12-21-2008, 01:54 PM
  #9
Senior Member

Join Date: Apr 2007
Posts: 621
Default Re: Is this tile layout the most efficient?

I assume you mean you have to "minimize cuts" AND lay it diagonally? The best way to do this is with a cad program. Draw the floor area to scale, create a tile and then array it in a rectangular array, taking into account your grout spacing. Then just move it around until it looks just right. After you get it the way you want it, you should easily be able to measure the tile points where they contact the wall.

CopyKat is offline
Old 12-21-2008, 02:43 PM
  #10
Senior MemberCaptains Club Member

Join Date: Aug 2002
Location: S. Galvez, Louisiana. Ame
Posts: 7,448
Default Re: Is this tile layout the most efficient?

Most efficient?

In what?

Number of tiles?

Number of cuts?

Lay out a square pattern to use less tile and with less cuts. However i like the 45* layout but it is not the most efficient.

For what it is worth, lay it out all the way to the wall, do not allow 3/4".
twentynine is offline
Old 12-22-2008, 03:04 AM
  #11
Senior MemberCaptains Club Member

Garett's Avatar

Join Date: Feb 2003
Posts: 24,119
Default Re: Is this tile layout the most efficient?

IMO forget about trying to save yourself a few cuts here and there when laying up a floor on the diagonal. When tiling small spaces or hallways the finish look always out weighs the effort it took to make it.

You’re asking us about layout, well I have to ask you, are you installing a vanity that goes right to the floor, a free standing vanity or a pedestal sink? The reason why I ask is because that determines how much floor will be exposed along the left side wall and that will/ should dictate the tile layout pattern. The pattern of tile layout should not be determined as an empty room, but more as a completed room.

If you do a full tile at the threshold (corner of the tile touches the threshold but not cut) then I think it would look bang on to offset your tile that 3/4" along the right hand wall (given your baseboard is 3/4"). Judging by your pics I think you’d have plenty of tile at the tub to look more then acceptable. But in saying that, I certainly wouldn’t be taking that approach if I were installing a pedestal sink and I would have to seriously think things through if I were installing a free standing vanity.
Garett is offline
Old 12-22-2008, 05:01 AM
  #12
Senior MemberCaptains Club MemberPLEDGER

Join Date: May 2005
Posts: 6,194
Default Re: Is this tile layout the most efficient?

Tryin to save cuts is a waste of time, especially in a room that small. If you want your pattern to be on the diagonal, shift everything over so your first tile starts in the center of your doorway. If not, you will end up with an eyesore on your hands.

You also need to measure the length of the room to determine the size of the first tile, so you do not have less than half a tile at the end of the room (See Reelescapes photo for reference).

No offense, but if you were to set the tiles the way you show them, it would scream DIY job.
RI Builder is offline
Old 12-22-2008, 05:37 AM
  #13
Senior MemberPLEDGERPLEDGERCaptains Club Member

Join Date: Sep 2004
Location: ATL & SAV
Posts: 12,247
Default RE: Is this tile layout the most efficient?

What they said. While you are thinking about it I would stuff a rag in the toilet and sink drain.
Tireless is offline
Old 12-22-2008, 05:44 AM
  #14
Senior MemberCaptains Club MemberPLEDGER

Join Date: May 2005
Posts: 6,194
Default Re: Is this tile layout the most efficient?

Oh, one other thing. Add a threshold at the doorway as well.
RI Builder is offline
Old 12-22-2008, 06:06 AM
  #15
Senior MemberPLEDGERPLEDGERCaptains Club Member

Join Date: Sep 2004
Location: ATL & SAV
Posts: 12,247
Default Re: Is this tile layout the most efficient?

RI Builder - 12/22/2008 8:44 AM

Oh, one other thing. Add a threshold at the doorway as well.
I have a few other suggestions...

1) If you have a bunch of tile you could continue the tile work up the walls approx. and really dress up the room.

or...

2) You could add an inexpensive 4ft to 5ft wainscoting addition as shown in this pic......

Tireless is offline
Old 12-22-2008, 02:40 PM
  #16
Senior MemberCaptains Club Member

Garett's Avatar

Join Date: Feb 2003
Posts: 24,119
Default Re: Is this tile layout the most efficient?

Oh hey blueh20pc, when you do get around to doing that floor, the white little rubber spacers, well they don't go the way you're showing in your pics. You've got one per a four tile corner, the proper way of using them is to use one rubber spacer standing upright about an inch in from the corner per tile. You are using one spacer per corner, whereas the proper way of using them is to have four spacers per corner. When use properly all one has to do is pull them out by hand after the thinset has cured.
Garett is offline
Old 12-22-2008, 02:52 PM
  #17
Senior Member

Join Date: Apr 2008
Posts: 545
Default RE: Is this tile layout the most efficient?

P.S.

Dont center your doorway like somebody suggested. That floor will turn out bad if you do. Lay off the right wall and door way with full diagonals for the best look for that particular room. Have fun.
gregGradyfish is offline
Old 12-22-2008, 08:32 PM
  #18
Senior MemberCaptains Club MemberPLEDGER

Join Date: Oct 2004
Location: North Myrtle Beach SC
Posts: 8,045
Default Re: Is this tile layout the most efficient?

Here is a online tile designer.

http://www.daltileproducts.com/dar.cfm#
kingair is offline
Old 12-22-2008, 10:56 PM
  #19
Senior MemberCaptains Club MemberPLEDGERPLEDGER

Join Date: Jan 2006
Location: Maui and SoCal
Posts: 7,103
Default RE: Is this tile layout the most efficient?

A different take here.....

It looks like you are using a ceramic tile. Every cut edge on ceramic tile is sharp, whereas the factory edges have some radius on them. If you use a stone tile, whether granite or travetine, you can restore the radius and give a finished edge to your cuts.

If you use travertine, you can finish it with a router. I am doing quite a bit of tile in my new house and I am wrapping up the base boards and onto the windowsills. My tile guy about fell over when I said "use a router", but it works like a champ. Adding a bullnose is simple, as is cutting around drywall corners. Here's a shot before it was grouted:

kerno is offline
Old 12-23-2008, 05:14 AM
  #20
Senior MemberCaptains Club Member

Join Date: Jul 2003
Location: Lancaster, PA
Posts: 1,018
Default RE: Is this tile layout the most efficient?

kerno - 12/23/2008 1:56 AM

A different take here.....

It looks like you are using a ceramic tile. Every cut edge on ceramic tile is sharp, whereas the factory edges have some radius on them. If you use a stone tile, whether granite or travetine, you can restore the radius and give a finished edge to your cuts.

If you use travertine, you can finish it with a router. I am doing quite a bit of tile in my new house and I am wrapping up the base boards and onto the windowsills. My tile guy about fell over when I said "use a router", but it works like a champ. Adding a bullnose is simple, as is cutting around drywall corners. Here's a shot before it was grouted:
Nice idea...what kind of bit are you using?
