Mercury 5.0 stalling issue

Old 09-14-2018, 04:55 PM
  #1
Member
Thread Starter

Join Date: May 2018
Posts: 42
Default Mercury 5.0 stalling issue

I have a mercury 5.0 inboard .when I start the boat it runs for a few seconds I add throttle in netral and the boat stalls. Ran fine all season. Any suggestions.its carb motor 5.0 thunderbolt ignition system.

thanks
sk7499 is offline
Old 09-15-2018, 07:13 AM
  #2
Admirals Club Admiral's Club Member

Join Date: Dec 2009
Location: New Jersey Shore
Posts: 2,232
Default

Could be a lot of things. Check the distributor cap and rotor. Moisture has a way of accumulating in there. Could also be the carb, maybe time for a rebuild. When is the last time you replaced spark plugs? (probably not that)
nickmo is offline
Old 09-15-2018, 07:19 AM
  #3
Senior Member

Join Date: Jun 2014
Location: SE GA
Posts: 152
Default

Condition of fuel?
DCSC is offline
Old 09-15-2018, 08:19 AM
  #4
Senior Member

Join Date: Jul 2016
Location: Perth WA
Posts: 2,072
Default

electric choke or mechanical ? , if electric, the choke may not be closing ,remove the flame arrestor and check when the motor is cold the butterfly is closing.
1breakinit is offline
Old 09-15-2018, 09:39 AM
  #5
Senior MemberCaptains Club Member

Join Date: Oct 2003
Posts: 7,514
Default

Probably the Idle Air Controller valve has failed.
Whaler27 is offline
Old 09-15-2018, 10:15 AM
  #6
Senior Member

Join Date: Jun 2014
Location: skittleville fl
Posts: 8,379
Default

You didn't read the OP did ya ? Carb engine.
Thalasso and 1breakinit like this.
mitchell master is offline
Old 09-15-2018, 11:12 AM
  #7
Member
Thread Starter

Join Date: May 2018
Posts: 42
Default

There is no iac. The gas is 2 weeks old I'm not sure maybe I didn't put enough staibliser. Sparks I don't know I've owned it for 1 year no maintaince records. Ran fine and now it's acting up.

so when I start it I push throttel forward 1 pump starts fine. Idles It then starts idling rough I pump throttle ones more runs for few seconds then dies.when I pump throttle it boggs engine down. Almost like I have no gas
sk7499 is offline
Old 09-15-2018, 02:04 PM
  #8
Member

Join Date: May 2016
Location: Dorchester/West Yarmouth, Ma
Posts: 71
Default

I had a similar issue this early this year - same engines. After all the regular items to check, I took the carb off and removed the top half, figured it may be gunked up or full of ethanol residue. The blue rubber piece on the accelerator pump was split. I had some pieces from an old rebuild kit and happened to have one. No issues since.
kalcris is offline
Old 09-15-2018, 02:06 PM
  #9
Senior Member

Join Date: Nov 2002
Location: Long Island, NY
Posts: 6,891
Default


Does the engine have a mechanical fuel pump or electric?
Do some more investigating. When it dies, take off the flame arrestor and get an led flashlight. Look into the primary barrels and pump the gas with the choke propped open by hand. If you see a squirt of fuel then the problem is not lack of fuel. But if no fuel is squirted when you do that, it could be the fuel pump or some carbs have a small filter in the carb inlet, this can get clogged (Not too likely if there is large water separating fuel filter, which most I/Os have as standard). You could also dump out that large filter into a mason jar and see how it looks, should look like this, if it has a layer of water on the bottom, you have water in the gas tank.
Thalasso likes this.
LouC is online now
Old 09-15-2018, 05:39 PM
  #10
Member
Thread Starter

Join Date: May 2018
Posts: 42
Default

Ok changed the fuel filter didn't solve the problem.
Next looked with a flashlight into carb. when I press throttle there is a squirt of gas that goes in the bowl. Here is what I see happening if I move the throtel more squirts of gas into bowl the engine will run for awhile longer and then dies out. My thought is it burns through the gas in the bowl and then dies out.

It has an electric fuel pump. I think it might be an oil pressure sensor.

Here is why. when I turn the key on I don't here the fuel pump turn on ...does anyone know I, does the fuel pump turn on automatically or does it turn on when the gas in carb is depleted?
I started to investigate the oil pressure sensor. When I took the connector off of the oil pressure sensor and jumped the leads minus the sensor and I turn the key I hear the fuel pump turn on and if I start the boat it runs but dies. Could it be this sensor. Will the motor stay running if I jump this sensor or does it need to be in the circuit?
sk7499 is offline
Old 09-15-2018, 05:47 PM
  #11
Member
Thread Starter

Join Date: May 2018
Posts: 42
Default

Originally Posted by 1breakinit View Post
electric choke or mechanical ? , if electric, the choke may not be closing ,remove the flame arrestor and check when the motor is cold the butterfly is closing.
its mechanical choke
sk7499 is offline
Old 09-15-2018, 06:18 PM
  #12
Senior MemberCaptains Club Member

Join Date: Oct 2003
Posts: 7,514
Default

Originally Posted by mitchell master View Post
You didn't read the OP did ya ? Carb engine.
What's a carb? Yea, missed the carb part. Just went reflexive on 5.0 won't run = IAC,
Whaler27 is offline
Old 09-16-2018, 05:18 PM
  #13
Senior Member

Join Date: Jan 2006
Location: Sunny florida
Posts: 23,032
Default

Idle mixture and idle speed. Simple adjustment.
billinstuart is offline
Old 09-16-2018, 06:28 PM
  #14
Member
Thread Starter

Join Date: May 2018
Posts: 42
Default

Idle mixture adjstment. Would I need to do this if before it ran fine with no issues. I dont want to mess with that yet as im not sure thats the issue ..as it starts idles fine then dies in like 10 seconds almost like starved for fuel. . if i pump more fuel before i start it will run longer maybe 15 to 20 sec. Just to add once I press the throttle forward it will die right away when it's started and running
sk7499 is offline
Old 09-16-2018, 09:48 PM
  #15
Senior Member

Join Date: Jul 2016
Location: Perth WA
Posts: 2,072
Default

looks like its time for a carb service .
1breakinit is offline
Old 09-17-2018, 05:33 AM
  #16
Senior Member

Join Date: Jan 2006
Location: Sunny florida
Posts: 23,032
Default

Originally Posted by sk7499 View Post
Idle mixture adjstment. Would I need to do this if before it ran fine with no issues. I dont want to mess with that yet as im not sure thats the issue ..as it starts idles fine then dies in like 10 seconds almost like starved for fuel. . if i pump more fuel before i start it will run longer maybe 15 to 20 sec. Just to add once I press the throttle forward it will die right away when it's started and running
It's made to play with. Probably lean. Fatten it up a little, won't hurt anything. Should be about 1-1/2 turns out to begin with. Adjust idle speed in gear, then adjust idle mixture. Lean it until it stumbles, go back 1/2 turn. Recheck idle speed in gear, recheck idle mixture. There is no preset idle mixture.

A carb does not need a constant supply of fuel. The float bowl holds enough fuel for the typical carb to idle for 30 seconds or so. Just like a lawn mower, when you shut off the fuel and run the carb dry.
billinstuart is offline
Old 09-17-2018, 08:23 AM
  #17
Admirals Club Admiral's Club Member

Join Date: Jun 2017
Posts: 527
Default

ignition on prior to starting the electric fuel pump with pump fuel
once the motor is running the fuel pump needs the oil pressure switch to read oil pressure to pump fuel. use an electrical tester to see if your fuel pump is getting power after the engine is running.

could be a bad oil pressure switch.

if it's the oil pressure switch it will consistently start up fine then die 30 seconds or a minute after starting.

if it's the oil pressure switch, you should be able to repeat this same sequence every time regardless if the engine is hot or cold.

something that's simple to test without removing any parts
outobie is offline
Old 09-17-2018, 01:32 PM
  #18
Member
Thread Starter

Join Date: May 2018
Posts: 42
Default

I'm close so when I messed with idle and mixture screw I got it running for over 5 minutes. The thing is it runs at 1000 rpms and every so often surges to 1200 rpms then back down. When I apply throttle fast it will stall it. If I add throttle slowly there is a bit of hesitation and a loud hiss noise then it kicks in.

We'll at least is started now I'm being pushed with maybe it's gummed up dirty carb but I use fuel stabliser each fillup.

Also to note when I take flame are stored off and spray chock cleaner into carb it revs up then down doesn't stall.

Any ideas everyone has been so helpful I appreciate the help so far.


If it gets running right do I need to keep adjusting the idle and mixture all the time as when I left the boat before all this occurred it was fine
sk7499 is offline
Old 09-17-2018, 02:46 PM
  #19
Senior Member

Join Date: Nov 2002
Location: Long Island, NY
Posts: 6,891
Default

It is possible that the switch that powers the pump (which is sensing the presence of engine oil pressure) is either defective or you have a bad or loose connection there. The way some electric pumps work, they get power from the S terminal as the engine is starting, and then oil pressure builds up. Once the engine starts, and the starter is disengaged (No current from S terminal) the contacts on the oil pressure switch close and power the pump. Take a look at this, not specifically a boat set up but same concept:
Electric Fuel Pump: How to Do It Right
LouC is online now
Old 09-17-2018, 02:59 PM
  #20
Member
Thread Starter

Join Date: May 2018
Posts: 42
Default

OK an update...kept messing with idle and fuel mixture screw .I got it to idle at 650 and when I push throttle now it responds. I let it warm up 20 minutes ran smooth responds to throttle quickly. I thought I had it fixed turned it off waited 1 min pumped gas with throttle once and turned key ...it won't start...did I flood the carb by adding throttle when engine was warm. I'm planning on doing sparks coils full tune up over the winter ...I just can't get this thing out of the marina with its issues.


sorry I come from fuel injected Generation and I'm not to familiar with carboarators but I'm learning
sk7499 is offline
