Boat lift question tight fit

Old 10-21-2020, 07:27 AM
  #1
Member
Thread Starter

Join Date: Jul 2014
Posts: 69
Likes: 0
Received 12 Likes on 8 Posts
Default Boat lift question tight fit

I wanted to see if someone has experience with 4 post lifts in tight spaces. our condo has slips that at 12' wide, i have an everglades 350lx with a 10.8' beam. is it possible and practical to put a 4 post lift in this space? would go with a Neptune high speed direct drive lift. if we remove the guide poles and use the pilings as guides would I be able to get the boat in and out of the slip? the canal is protected and the boat has a thruster and joystick so docking into tight spots is not an issue.

12' slip width using 10" pilings I would lose 10" total taking both sides into account on the inside to inside dimension, that would leave 11' 2" .

anyone have experience with this?
Old 10-21-2020, 07:33 AM
  #2
Senior MemberCaptains Club Member

Join Date: Jan 2007
Location: Tampa Florida
Posts: 6,552
Received 3,108 Likes on 1,779 Posts
Default

this is something you need to discuss on site with the dock/lift installer!
Likes:
Old 10-21-2020, 07:43 AM
  #3
Senior MemberCaptains Club MemberPLEDGER

Join Date: Jan 2005
Location: Suburb of Sugar Tit SC
Posts: 14,117
Received 9,161 Likes on 4,933 Posts
Default

Can you inset the pilings into the dock?
Old 10-21-2020, 09:29 AM
  #4
Senior MemberCaptains Club Member

Join Date: Jan 2003
Location: Charleston, SC
Posts: 3,383
Received 3,831 Likes on 1,709 Posts
Default

Here's a pic of my Back Cove 29 on a Hi Tide 12k lb lift with standard piling spacing. The BC has a 10'6" beam.
Pilings are 10" diameter and are on 12'6" centers beam-wise.
The guide poles are near the end of the cradle beams but there was a bit further it could go, although it was tight.
I cut up an old boat fender to cover the ends of the top beams and some of the piling on the entrance pilings to prevent gelcoat damage. I have tidal current so would generally only load during slack high tides.
If you can keep guide poles, they do keep the side of the boat off the top beams. Although pilings can be tough on fiberglass, they're not near as destructive as metal parts can be.
Hope this helps..


Old 10-21-2020, 10:08 AM
  #5
Senior MemberCaptains Club Member

Join Date: Oct 2004
Location: Ocean City, NJ
Posts: 2,233
Received 398 Likes on 228 Posts
Default

My Southport was on the same lift as Coastboater. As he mentions, 12'6" centers for pilings. As you can see, the beams are inside of the pilings, but are equal to the 12' 6" center to accept the cable coming down from the upper beams. I would not want a lift without guide poles. They actually help you get the boat on the lift, and more importantly show you when the lift is low enough under water, (with tape marking on the PVC poles), for you to safely approach the lift cradle. Without that, you could easily hit the cross beams if the lift is not deep enough. With the Southports 10'6" beam, my guide poles were also at the end of the beams, and would not allow for a cat-walk. You are going to be tight, depending on your actual slip width, and regulations from your condo.
Old 10-21-2020, 11:25 AM
  #6
Admirals Club Admiral's Club Member

Join Date: Jun 2009
Location: Ft Pierce Fl
Posts: 106
Likes: 0
Received 2 Likes on 2 Posts
Default

I install hi tide lifts you are going to lose depending on the pile diameter about 20inches of width of the slip. Take into account that piles are not perfectly straight any dog leg in the pile could decrease the space available. 16ft slip would be idea.
Old 10-21-2020, 12:42 PM
  #7
Admirals Club Admiral's Club Member

Join Date: Nov 2009
Location: Tarpon Springs, FL
Posts: 8,295
Likes: 0
Received 3,968 Likes on 2,239 Posts
Default

Wouldn't a lift big enough for that boat be a 6 post lift?
Old 10-21-2020, 01:41 PM
  #8
Admirals Club Admiral's Club Member

Join Date: Jul 2018
Location: tallahassee fl
Posts: 303
Received 133 Likes on 75 Posts
Default

side mount it on the outside of the posts, motors will not encroach in your limited space like the pic above. you'll need longer beams but that should be no problem
Old 10-21-2020, 04:46 PM
  #9
Senior MemberCaptains Club Member

Join Date: Dec 2002
Location: Myers Beach, FL, USA
Posts: 3,343
Received 449 Likes on 291 Posts
Default

Originally Posted by awalchli View Post
I wanted to see if someone has experience with 4 post lifts in tight spaces. our condo has slips that at 12' wide, i have an everglades 350lx with a 10.8' beam.

12' slip width using 10" pilings I would lose 10" total taking both sides into account on the inside to inside dimension, that would leave 11' 2”.
Comments:

1. You don’t indicate whether there is a finger pier, its width, its length, or whether fixed or floating. This will certainly affect where you can place at least one of your pilings.

2. Your math seems a bit faulty. If your slip is 12ft wide and you have 10” pilings on each side, inside your slip boundary, then you lose 20”, not the 10” in your post, so only 10’4” between the interior faces of the pilings. And that assumes they are perfectly vertical and perfectly straight. So, your boat will not fit even without guide poles.

3. You don’t indicate the length of your condo slips, or restrictions on projecting beyond the outer boundary, but 12ft wide slips probably aren’t long enough for your boat. JMHO.

We lived in a condo in Norfolk, VA from 2004-2015, and purchased a slip. They offered 12x25, 14x30 and 17x35. We were not allowed to project outside our slip - an excellent rule for both safety and ascetics - so we bought the largest slip for the boat in my signature.

Last edited by ocnslr; 10-21-2020 at 04:55 PM.
Old 10-21-2020, 04:57 PM
  #10
Senior Member Admiral's Club Member

Join Date: Jun 2009
Location: Lighthouse Point, Fl.
Posts: 2,495
Received 734 Likes on 355 Posts
Default

Originally Posted by awalchli View Post
I wanted to see if someone has experience with 4 post lifts in tight spaces. our condo has slips that at 12' wide, i have an everglades 350lx with a 10.8' beam. is it possible and practical to put a 4 post lift in this space? would go with a Neptune high speed direct drive lift. if we remove the guide poles and use the pilings as guides would I be able to get the boat in and out of the slip? the canal is protected and the boat has a thruster and joystick so docking into tight spots is not an issue.

12' slip width using 10" pilings I would lose 10" total taking both sides into account on the inside to inside dimension, that would leave 11' 2" .

anyone have experience with this?
Had a narrow issue back in the not missed condo days. After "musical chairs" got two slips next to each other and pulled the center piling.
